Print this page Hurricane Resistant - HIGT6700 Series Casement
Casement Window
Frame Depth (inches) 3.0
Description New and improved highly energy efficient window, for hurricane-impact resistance, with a historic window profile. The newly designed GT6700 incorporates European thermal strut technology for optimum thermal efficiency and low U-values. Achieving AAMA AW rated in all configurations with minimum air infiltration, high water resistance and impressive design pressures.
- Applications
- Hurricane Resistant
Test Size (inches)
42 x 78
Air Infiltration (cfm/ft2)
<0.10
Water Resistance (psf)
12
Design Pressure Positive (psf)
+70
Design Pressure Negative (psf)
-90
U-Value
0.38 - 0.43
CRF
65
Test Method
AAMA 506-16, ASTM E 1886-12, ASTM E 1996-17
Large Missle
Meets
Small Missle
Meets
Notes
FL Approval # 38534.1 (42 x 78)
The air infiltration and water resistance performance values provided above were achieved in a controlled lab environment. Performance of our products in the field will vary depending on product configurations, installation methods, and ambient conditions. AAMA 502 “Voluntary Specification for Field Testing of Newly Installed Fenestration Products” should be adhered to for testing installed products.
Standard Features
- Inswing/Outswing Casement windows for hurricane-impact resistance
- Provides large/small missile impact protection
- 3” Frame Depth
- 1-5/8” slim sightline historic profiles
- Reduced number of parts for better product performance and integrity
- Euro-grooves to accommodate multiple hardware options and accessory applications
- Superior joinery allows for larger units and more configurations
- Deep sloped exterior glazing leg
- Multiple glazing depths available
- Fixed/Operable intermediate design offers minimal sightlines
- Design allows multiple units into one opening simplifying installation
- Larger thermal strut technology for excellent thermal performance
- Concealed hinges
- 4-inch limited opening device
Optional Features
- True and exterior applied muntin grids
- Concave frame and muntins
- Equal sightline frame
- Roto operators
- Single lever operator
- Eliminates need for wicket screens
- Can assist with meeting ADA operational forces - Multi-point locking system
- Dual finish (two-tone color) option
